Features:
| Model | Carrier Weight |
Working Weight |
Overall Length |
Frequency | Operating Pressure | Oil Flow | Impact Energy |
Working Tool Diameter |
|---|---|---|---|---|---|---|---|---|
| ton | lb | in | bpm | psi | gpm | ft lb | in | |
| TF-01 | 0.7 - 2.5 | 280 | 47 | 700 - 1,250 | 1,450 - 1,885 | 3.9 - 6.6 | 80 | 1.7 |
| TF-02 | 1 - 3.5 | 280 | 47 | 700 - 1,170 | 1,450 - 1,885 | 5.2 - 9.2 | 90 | 1.9 |
| TF-03 | 1.5 - 4.5 | 337 | 49 | 550 - 1,000 | 1,450 - 1,885 | 5.2 - 9.2 | 400 | 2.2 |
| TF-04 | 2.5 - 6 | 551 | 57 | 550 - 1,000 | 1,595 - 2,030 | 7.9 - 13.2 | 500 | 2.4 |
| TF-05 | 3.5 - 8 | 644 | 66.2 | 550 - 1,000 | 1,885 - 2,465 | 9.2 - 17.1 | 750 | 2.6 |
| TF-06 | 5 - 11 | 946 | 76.1 | 540 - 1,000 | 1,885 - 2,465 | 11.8 - 23.7 | 1,200 | 3.1 |
| TF-10 | 7 - 15 | 1,313 | 81.2 | 540 - 1,000 | 2,030 - 2,610 | 15.8 - 29 | 2,000 | 3.6 |
